SHANGFAN KAYAN KAPI SERISI
İz bırakmayan itme-çekme sistemi ile modern yaşam alanları için tasarlanmış yüksek kaliteli kayan kapı serisi.
Kategori:
Kapı Serileri
Open method:
Trackless Push-Pull
Customize cycle:
20-30 days
hardware:
Standard OPEIK hardware
Glass Configuration:
8mm tempered white glass
Railway:
Single track, two tracks, three links
Optional color:
Matte white, matte black, cool gray
Energy-saving features:
PA66 High-performance Insulation Strip
Profile Spec:
Wall thickness: 2.5 mm Frame: 12*37 mm
Applicable scenarios:
balcony, bedroom, study, office and other scenarios
Sliding fan dimensions:
Single-panel size range: width 650-900mm, height ≤2500mm.
Minimum pricing area:
less than 1.5 square meters per panel is priced at 1.5 square meters.
Package:
Single or double package • 1. Two tracks single package minimum wall thickness 122mm, double package minimum wall thickness 142mm • The minimum wall thickness for single-track three-track systems is 186mm, and for double-track systems, it is 206 mm. • 2. Wall Covering:40mm;
